JL811A Aruba Instant On 1830 8G 4p Class4 PoE 65W Switch

JL811A Aruba Instant On 1830 8G 4p Class4 PoE 65W Switch

Mã sản phẩm: JL811A
Nhà sản xuất:
Bảo hành: 24 tháng

  • 8 Cổng RJ45 10/100/1000Mbps

  • Cổng 1-4 cấp nguồn PoE 802.3 af/at

  • Tổng công suất cấp nguồn POE: 65W

  • Hỗ trợ VLAN IEEE 802.1Q: 256 VLAN

  • Quản trị : Aruba Instant On Cloud; Web browser; SNMP

  • Switch Throughput: 11.90 Mpps

3,400,000 VNĐ

Số lượng:

Sản phẩm liên quan

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

1,580,000

0

0

0

0

0

0

0

0

0

0

0

4,257,000

2,850,000

0

5,750,000

2,375,000

0

0

0

15,990,000

3,400,000

13,239,000

18,725,000

3,920,000

9,492,000

3,130,000

1,199,000

56,160,000

22,850,000

0

0

8,110,000

0

17,325,000

6,910,000

0

0

4,950,000

9,999,000

9,999,000

3,580,000

Model JL811A
I/O ports and slots 8 RJ-45 autosensing 10/100/1000 ports IEEE 802.3at Class 4 PoE (ports 1-4) (IEEE 802.3 Type 10BASET, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T);
Duplex: 10BASET/100BASETX: half or full; 1000BASE-T: full only
Physical Characteristics
Dimensions  195.1(d) x 245.1(w) x 43.9(h) mm
Weight  1.54 kg
Processor and Memory ARM CortexA9 @ 800MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5MB
Performance
100 Mb latency < 5.2 uSec
1000 Mb latency < 2.8 uSec
Throughput (Mpps)  11.90 Mpps
Capacity  16 Gbps
MAC address table size 8,000 entries
Reliability MTBF (years)  105.9
Environment
Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative humidity 15% to 95% @ 104°F (40°C)
Nonoperating/ storage
temperature		 -40°F to 158°F (-40°C to 70°C)
Nonoperating/ storage relative
humidity		 15% to 95% @ 140°F (60°C)
Altitude up to 10,000 ft (3 km)
Acoustics Fanless
Electrical Characteristics
Frequency 50Hz/60Hz
AC voltage 100-127VAC / 200- 240VAC
Current 1.0A/0.5A
Maximum power rating 100-127V: 86.07W
200-220V: 83.67W
Idle power 100-127V: 8.3W
200-220V: 8.2W
PoE power 65 W Class 4 PoE
Power Supply Internal power supply
